CPU. . Support Intel® Core Ultra Processors(Series 2) , LGA1851*. Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**. * Refer to https://www.asus.com/support/download-center/ for CPU support list.. ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.. . Chipset. . Intel® B860 Chipset. . Memory. . 4 x DIMM slots, max. 256GB, DDR5. Support up to 8666+ MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)*''. Dual channel memory architecture. Supports Intel® Extreme Memory Profile (XMP) memory module. ASUS Enhanced Memory Profile III(AEMPIII). * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/.. **Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.. . Graphics. . 1 x DisplayPort**. 1 x HDMI port***. 1 x USB 20Gbps port (USB Type-C®) supports DisplayPort video output****. * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.. ** Supports max. 4K@60Hz as specified in DisplayPort 1.4.. *** Supports 4K@60Hz as specified in HDMI 2.1.. ****Supports max. 4K@60Hz as specified in DisplayPort 1.4.. ***** VGA resolution support depends on processors' or graphic cards' resolution.. ******While installing the operating system, please ensure that your monitor is connected to the HDMI port on the back I/O panel or to a discrete graphics card.. . Expansion Slots. . Intel® Core Ultra Processors(Series 2). 1 x PCIe 5.0 x16 slot. Intel® B860 Chipset. 1 x PCIe 4.0 x16 slot (supports x4 mode)*. 1 x PCIe 4.0 x1 slot*. * PCIEX16(G4) shares bandwidth with PCIEX1(G4). When PCIEX1(G4) runs at PCIe x1 mode, PCIEX16(G4) will only run at PCIe x2 mode.. - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals.. . Storage. . Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports*. Intel® Core Ultra Processors(Series 2)*. M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode). Intel® B860 Chipset. M.2_2 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode). M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode). 4 x SATA 6Gb/s ports. * Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10.. . Ethernet. . 1 x Realtek 2.5Gb Ethernet. TUF LANGuard. . Wireless & Bluetooth. . Wi-Fi 7*. 2x2 Wi-Fi 7 (802.11be). Supports 2.4/5/6GHz frequency band**. Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.. Bluetooth® v5.4***. *Wi-Fi features may vary depending on the operating system. For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only support Wi-Fi 6E.. For Windows 10, please note that no driver is available , please refer to the Wi-Fi chipset vendor's website for details.. ** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.. *** The Bluetooth® version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.. . USB. . Rear USB (Total 8 ports). 1 x USB 20Gbps port (1 x USB Type-C®). 2 x USB 10Gbps ports (2 x Type-A). 3 x USB 5Gbps ports (3 x Type-A). 2 x USB 2.0 ports (2 x Type-A). Front USB (Total 5 ports). 1 x USB USB 10Gbps connector (supports USB Type-C®). 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports. 1 x USB 2.0 header supports 2 additional USB 2.0 ports. USB Type-C® power delivery output: max. 5V/3A. . Audio. . Realtek 7.1 Surround Sound High Definition Audio CODEC*. - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking. - Supports up to 24-Bit/192 kHz playback''. Audio Features. - Audio Shielding. - Rear optical S/PDIF out port. - Premium audio capacitors. - Dedicated audio PCB layers. - Audio cover. * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.. . Back Panel I/O Ports. . 1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode). 2 x USB 10Gbps ports (2 x USB Type-A). 3 x USB 5Gbps ports (3 x Type-A). 2 x USB 2.0 ports (2 x Type-A). 1 x DisplayPort. 1 x HDMI port. 1 x Wi-Fi module. 1 x Realtek 2.5Gb Ethernet port. 5 x Audio jacks. 1 x Optical S/PDIF out port. 1 x BIOS FlashBack button. 1 x USB 20Gbps port (1 x USB Type-C® with DP Alt mode). 2 x USB 10Gbps ports (2 x USB Type-A). 3 x USB 5Gbps ports (3 x Type-A). 2 x USB 2.0 ports (2 x Type-A). 1 x DisplayPort. 1 x HDMI port. 1 x Wi-Fi module. 1 x Realtek 2.5Gb Ethernet port. 5 x Audio jacks. 1 x Optical S/PDIF out port. 1 x BIOS FlashBack button. . Internal I/O Connectors. . Fan and Cooling Related. 1 x 4-pin CPU Fan header. 1 x 4-pin CPU OPT Fan header. 1 x 4-pin AIO Pump header. 4 x 4-pin Chassis Fan headers. Power Related. 1 x 24-pin Main Power connector. 2 x 8-pin +12V CPU Power connectors
